56V MAX* 42 in. Battery-Powered Brushless Zero-Turn Mower

PROUDLY MADE IN THE USA with global materials in Martin, Tennessee; Battery assembled in Mexico
BRUSHLESS POWER: 56V MAX* (60Ah) Lithium Ion battery with four brushless motors designed for excellent performance
OPTIMAL PERFORMANCE: Up to 1.5 hours of runtime** & mows 3.5 acres of grass per charge**

View more features

Product Overview

Take Charge Of Your Yard With The 56V MAX* 42-in. Battery-Powered Brushless Zero-Turn Mower. Bring on the power and performance with four brushless motors allowing you to mow up to 3.5 acres of grass per charge**. Need to mow early or late, we have you covered with the mower being 75% quieter than gas+. The mower is equipped with LED headlights, helping illuminate the path you are mowing in low-light situations. Ride in comfort with a cut-and-sew high back seat and a quick lift assist when you need to raise the deck quickly to mow over roots or need to clear a threshold during storage.

Additional Features

NOISE REDUCTION: 75% quieter than gas+
DURABILITY: 42-in. stamped steel deck
LED HEADLIGHTS: Help illuminate the path in low light situations
RIDE IN COMFORT: Cut-and-sew high-back seat designed for a comfortable ride
ECO-MODE: Designed to reduce blade tip speed to conserve power and provide longer runtimes
QUICK LIFT ASSIST: Features a foot deck lift to quickly raise the deck when mowing over roots or need to clear a threshold during storage
BAGGING CAPABILITY: Compatible with CRAFTSMAN baggers (baggers sold separately)

Includes

(1) CMXGRAM211302

Specifications

Battery Capacity [Ah]	60
Battery Run Time Acreage	3.5
Battery Source	Rechargeable internal Li-Ion
Battery Voltage [V]	56
Battery Warranty	4 Years Limited
Charge Time [min]	240
Deck Construction	Stamped
Deck Gauge [GA]	13
Deck Lift Method	Foot and Pin
Forward Speed [mph]	7
Frame Warranty	5 Years Limited
Front Wheel Size [in]	11
Has Deck Wash?	No
Has Front Caster Suspension?	No
Has Headlight(s)?	Yes
Has Hitch?	Yes
Has Hour Meter?	Yes
Has Rubber Floor Mat?	Yes
Has USB Charger?	Yes
Maximum Cutting Height [in]	1
Minimum Cutting Height [in]	4.5
Mower Deck Width [in]	42
Number of Cutting Positions	15
Power Source	Battery
PTO (Blade Engagement)	Electric
Rear Wheel Size [in]	20
Recommended Terrain	Slight Hills
Reverse Speed [mph]	3.5
Seat Height Type	High-Back
Transmission Type	Brushless Motors
Watt Hour [Wh]	3000

0 of 0

Support

Warranty

3 Year Limited Warranty, 5 Year Frame, 4 Year Battery

We're confident of the quality of our products and we'll repair, without charge, any defects due to faulty materials or workmanship within the specified warranty.

Learn more

Service

We take extensive measures to ensure all our products are made to the very highest standards and meet all relevant regulations.

Learn More

QUEBEC DISCLOSURE: CRAFTSMAN Canada does not guarantee the availability of replacement parts, repair services or information necessary to maintain or repair products subject to and under the meaning of the Quebec Consumer Protection Act, as amended by Bill 29.

Download PDF

DIVULGATION POUR LE QUÉBEC: CRAFTSMAN Canada ne garantit pas la disponibilité de pièces de rechange, de services de réparation ou de renseignements nécessaires à l’entretien ou à la réparation de produits assujettis à la Loi sur la protection du consommateur du Québec, telle que modifiée par le projet de loi 29.

Télécharger le PDF

Manuals

Disclaimer(s)

* Maximum initial battery voltage (measured without a workload) is 56 volts. Nominal voltage is 50.4 volts.
** Per Charge, minimal cutting load, using discharge cutting mode, Eco mode not engaged, and highest cutting position at full speed with a CRAFTSMAN 56V MAX* 60Ah batteries.
+ vs CRAFTSMAN Z5200 CMXGNAM211701 gas mower, measurements taken from the operator position in a lab environment
